specification
technical indicators
|
number |
project |
technical indicators |
| 1 |
power supply |
3ph 380v，50hz 50kw |
| 2 |
compressed gas |
0.4-0.6mpa |
| 3 |
ambient temperature |
≤28℃ |
| 4 |
relative humidity |
rh ≤85% |
| 5 |
working pressure |
≤30mp |
| 6 |
pressure precision |
10kn |
| 7 |
compacted thickness of pole piece |
≤±0.002mm(incoming≤±0.003mm) |
| 8 |
roll straightness |
≤±0.0015mm |
| 9 |
radial runout of roller grinder |
≤±0.0015mm |
| 10 |
radial runout of roll loader |
≤±0.0025mm |
| 11 |
roll surface roughness |
ra≤0.2 |
| 12 |
rectifying accuracy |
±0.25mm |
| 13 |
outline size |
according to the technical agreement |
features
the main body of the machine consists of three pressing rollers, one datum roller and two pressing rollers. the two processes of pre pressing and constant thickness pressing are completed in one time. the pre pressing roller is arranged horizontally, and the constant thickness roller is arranged up and down, the servo valve is used to control the gap and pressure of the roll. the pressure is stable and the precision is high. it can solve the major problems of the old-fashioned film rolling machine, such as the head fragment, the tablet extension, the edge of the foil line, the different density of single and double sides compaction, and the impact of large gap running belt.
scope of use
lithium iron phosphate, lithium cobalt, lithium manganate, ternary, lithium nickel cobalt manganate and other systems; positive and negative coating processes for oily and aqueous systems; and continuous film rolling processes for positive and negative plates of batteries for super capacitor coating systems.
